One architecture. Two aircraft. Built to work.
Vulcan SX: Medium-lift Compact UAS
Vulcan YX: Heavy-lift Multimodal UAS
Built for the work ahead: Built by operators for operators
Radar inside
Forward collision avoidance
Active terrain following
Integrated RTK GNSS
Accuracy for every mission
No subscription
Flight Deck v4 for mission planning
SMART
Active terrain following
Forward collision avoidance
RTK GNSS, Dual-band L1/L5
Smart battery with extended flight packages
Onboard edge computing
Why Vulcan?
There’s a lot of noise out there about drones. Vulcan is built for the work ahead so you can cut through the noise.
Vulcan S
SAFE
IP54 rain rated
Low EMI / RFI armored design
Fault-tolerant, fully redundant power architecture
ASTM F3298-19 compliant
EASY TO USE
Flight Deck v4 (no subscription)
Field swappable payloads without tools
Smart dovetail
Vulcan YX
Talk to someone who’s flown it
Just the facts
Vulcan SX
Medium-lift Compact UAS
All shared Vulcan platform features
AIRFRAME TYPE: Multirotor Tricopter
PAYLOAD: Up to 3kg
PAYLOAD MOUNTS: Top or Belly
ENDURANCE: Up to 65 min (typical 45 min)
TOP SPEED: 17.5 m/s (40 mph)
WIND TOLERANCE: 12 m/s (25 mph)
TRANSPORT: Pelican case, checked baggage
OPERATING TEMP: 15° F - 115° F
Vulcan YX
Heavy-lift Multimodal UAS
All Vulcan Platform features
AIRFRAME TYPE: OFFSET Y-6
PAYLOAD: Up to 10kg (multimodal)
ENDURANCE: Up to 60 min
heavy payload config up to 15 kg / 10 min
TOP SPEED: 20 m/s (45 mph)
WIND TOLERANCE: 15 m/s (33 mph)
TRANSPORT: Pelican case
OPERATING TEMP: 15° F - 115° F
Payloads
Vulcan platform supports all Vision Aerial offered payloads
Contact us if you have questions about any payload, including one you don’t see as available.
Why it works in the field
Payload versatile.
Complete all your missions in one trip with field-swappable payloads — even if you forgot your tools. Vulcan YX is multimodal so you can fly multiple payloads simultaneously.
Data ready.
Collect good quality data, easily upload into your workflow without needing the battery plugged in, be a hero.
Easy to fly.
Accomplish more in your day with intuitive controls, advanced stability, and quick deployment. An all new Flight Deck mission planning system is still subscription free.
Portable.
Check drone transport off your worry list. Both Vulcan SX and Vulcan YX come standard with a Pelican transport case. Vulcan SX it lightweight so you can toss it in a car, truck or ATV. Even carry it on foot.
Next
Steps
Decide which UAS you need —
SX medium-lift or YX heavy-lift
1
Schedule a chat with an expert
2
Request a Quote for your Vulcan SX flight-ready bundle, or get on the pre-order list for Vulcan YX.
